Toll Barrier Gate Ordinary Straight Boom Dc Remote Control System Security Parking Barrier Gate

Name: Toll Barrier Gate Ordinary Straight Boom Dc Remote Control System Security Parking Barrier Gate
Brand: Ankuai
Price: 1 USD

Buy cheap Toll Barrier Gate Ordinary Straight Boom Dc Remote Control System Security Parking Barrier Gate product

Brand Name : Ankuai

Model Number : AKS580

Certification : ISO9001, CE Certificate

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, T/T, Western Union

Supply Ability : 30000 sets per Month

Delivery Time : 3 Work days for sample

Packaging Details : Regular package way with carton

Cabinet Dimension : 344*283*1019mm

Motor : DC24V Brushless motor

Motor Power : 100W

Speed Rate : 1.8/3s/6s

key Words : Barrier Gate

Working Temperature : -30°C~+80°C

istance : within 30m

Boom Type : Straight/ Folding/LED/ Fence/ Telescopic

Warranty : 12 months

Trade Terms : EXW, FOB, CIF

OEM/ODM : Support

Boom Length : 6m (maximum, adjustable)

Usage Direction : Bi-Direction

Contact Now

Toll Barrier Gate Ordinary Straight Boom Dc Remote Control System Security Parking Barrier Gate

Product Specifications

Parameter	Details
Material	Cold-rolled Steel
Place of Origin	Guangdong, China
Brand	AnKuai
Protection Rate	IP54
Product name	Barrier Gate
Product model	AKS580
Size	3442831020mm
Opening and closing times	1.8s/3s/6s
Boom Length	2~6m (Maximum, Adjustable)
Color	Black, White, Red, Orange, Customized
Moter	DC24V Brushless motor

Technical Specifications

Speed Time	1.5s	3s	5s	1.8s	3.5s	5.5s	6s
Boom Type	Straight Boom	Straight Boom	Straight Boom	Folding Boom	Folding Boom	Folding Boom	Fence Boom
Boom Length	3m	4.5m	6m	3m	4.5m	6m	5m

Mechanical Features

A sturdy, waterproof chassis built for outdoor environments.
An integrated movement system—with all components produced via full molding—ensures stability and precision.
A precision four-bar linkage delivers smooth operation, minimizing vibration and prolonging service life.
A 100W gear reducer provides quiet, compact transmission alongside shock-free stall protection.
A manual locking mechanism enables easy manual operation when power is cut off.

Smart Parking Barrier Features

Loop detector connector is available.
Auto-delay when closing(adjustable).
Automatic arm open function when powered off.
Infraed sensor signal anti-smashing interface.
The operation speed can be adjusted from 1.8s to 6s.
High-sensitivity arm auto-reverse function.
The arm automatically locks when powered off and opens the barrier gate by hand.
Arm swing-out function: when the vehicle hits the barrier gate, the arm can swing out to avoid further damage to the vehicle and barrier machine core.

Toll Barrier Gate Ordinary Straight Boom Dc Remote Control System Security Parking Barrier Gate

1. Access Control: Boom barriers are primarily used to control and regulate vehicle access to specific areas such as parking lots, residential complexes, industrial sites, and other restricted zones.

2. Security: They serve as a physical barrier to prevent unauthorized vehicles from entering restricted areas, enhancing overall security measures.

3. Traffic Management: Boom barriers help in managing vehicle flow, directing traffic, and preventing congestion in parking areas or entry/exit points.

4. Automation: Many boom barriers are equipped with automation features that allow for automatic opening and closing based on triggers such as RFID cards, sensors, or remote controls.

5. Safety: Boom barriers are designed with safety features to prevent accidents, including sensors that detect obstructions and mechanisms to stop the barrier from closing on a vehicle or person.

6. Customization: They can be customized in terms of size, design, and additional features to meet specific user requirements and site conditions.

7. Integration: Modern boom barriers can be integrated with access control systems, CCTV cameras, and other security devices to provide a comprehensive security solution.

8. Durability: Boom barriers are built to withstand harsh weather conditions and heavy usage, ensuring long-term reliability and performance.

9. Monitoring: Some boom barriers come with monitoring capabilities that allow users to track and log vehicle entries and exits for security and management purposes.

10. Remote Control: With the advancement of technology, remote control and monitoring of boom barriers have become common, enabling users to operate the barriers from a centralized location for convenience and efficiency.

Safety First: Multi-Layer Protection

Obstacle Detection: Instant arm reversal when an obstruction is sensed during descent.
Ground Sensor Priority: Overrides closing commands when a vehicle is detected.
Physical Safety: Anti-smash rubber strips and high-density foam arm reduce impact risk.

Easy Installation & Maintenance

Concrete Base: 150mm larger than the unit, 200mm thick for stability.
Spring System: Pre-matched for balance; adjustable tension via simple handle rotation.
Troubleshooting: Clear error codes (e.g., EFF-01 for hall faults, EFF-02 for undervoltage) and self-diagnostic functions.

Ideal for Various Scenarios

Parking garages, toll stations, and industrial compounds
Facilities requiring high-security access control
Environments with extreme temperatures or high traffic flow
